Specification: Main body regulation:--------------------------------- -------------------------0.5 U
Group amount:--------------------------------------------------------------1 groups
ReCeiver's material:------------------------------metal main body and panel
Oscillation mode:-------------------------------------------------PLL synthesized
Frequency stability:--------------------------------------------------------±0.005%
Frequency range:-----------------------------------------------------798~830MHz
Frequency alternation:-------------------------------------------------------32MHz
Operate mode:--------------------------------------------------manual adjusting
Receiving way:---------------------------------------------------------single tuning
Sensitivity:---------Deviation 25KHz, when connected 7dBuV, S/N>78dB
Max Deviation:---------------------------------------------------------------±48KHz
Frequency response:-----------------------------------------50Hz- 15KHz±3dB
Transmitter output power:-------------------------------------------------100mW
AF input:-----------------------------------------------------------XLR, 6.3mm&jack
Earphone output:----------------------------------------6.3mm&Double socket
Current consumption:--------------------------------------------DC 12V/110mA
Antenna socket:---------------------------------------------------------TNC socket
UHF Wireless Microphone
