Senpro Audio Equipment Co.,Ltd.

System:
Audio Frequency Response----------------80-12000Hz
Dynamic Range--------------------------------------- ≥80dB
System Distortion--------------------------------------- ≤1%
Signal-to-Noise Ratio----------------------------- -- ≥80dB
Operating Range-----------------------------------Appr.80M
Operating Temperature Range---------------5℃〜45℃
Carrier Frequency Range-------------------790-870MHz
Receiving System----------------------Diversity Receiver

Receiver:
Sensitivity (S/N=30dB)------------------------------- > 2mV
Image Rejection--------------------------------------＞60dB
De-Emphasis--------------------------------------------50μS
Audio Output Impedance-----------------------------600Ω
Audio Output Level--------------------------------------1.1V
Power Supply-------------------AC220V~240V 50/60Hz
Current Consumption---------------------------- ≤300mA

Handheld Transmitter:
Frequency Stability-------------------------------±0.001%
RF Output Power----------------------------------- ≤30mW
Spurious Rejection---------------------------------＞50dB
Modulation Mode------------------------------------------FM
Maximum Deviation Range--------------------±45KHz
Microphone Mode---------------------------------Dynamic
Pre-Emphasis------------------------------------------50μS
Power Supply--------------------------DC 3V (AA1.5V×2)
Current Consumption------------------------------≤40mA
Dimensions----------------------------------φ35×270mm
Weight---------------------------------Appr.250g(No Batt.)

Body-pack Transmitter:
Frequency Stability-------------------------------±0.001%
RF Output Power----------------------------------- ≤30mW
Spurious Rejection---------------------------------＞50dB
Modulation Mode------------------------------------------FM
Maximum Deviation Range---------------------±45KHz
Microphone Mode------------------------------Condenser
Pre-Emphasis-------------------------------------------50μS
Power Supply------------------------------------------DC 9V
Current Consumption------------------------------≤40mA
Dimensions----------------------------------95×60×20mm
Weight------------------------------------Appr.90g(No Batt.)
