*Wide UHF 600-900MHz frequency, 200 selectable channels

*Flexible, simple and convenient to operate

*Advanced digital PLL to ensure the unit in high stability and wide frequency response

*LCD display screen

*MCU intelligent control enhances the system status, analyses signals and blocks noises to make the sound perfect

*Dual sound effect compress and expand function offer higher S/N ratio and larger dynamic range

*Multiple squelch control circuit helps to get rid of the external interference

*Unique design, powerful dynamic and wide frequency response are the perfect choice for KTV, live performance and other occasions





System Specification

Frequency Range: UHF 600-900MHz

Modulation: PLL

Adjustable Range: 50MHz

Channel: 2x100

Frequency Interval: 250KHz

Frequency Stability: within ±0.005%

Dynamic Range: 100dB

Maximum Frequency Deviation: ±45KHz

Frequency Response: 80Hz-180KHz ±3dB

S/N: >105dB

T.H.D: ≦0.5%





Receiver Specification

Receiver Mode: Double Conversion Superheterodyne

Intermediate Frequency: First: 110MHz, Second: 10.7MHz

Wireless Interface:BNC/50WΩ

Sensitivity: 12dBμV(80dBS/N)

Sensitivity Adjustable range: 12-32dBμV

Spur Suppression: ≧75dB

Maximum Output Level: +10dBV





Transmitter Specification

Antenna Mode: Backpack transmitter equips with 1/4 wave whip antenna, handheld microphone equips with built-in helical antenna

Output Power: High: 30mW, Low: 3mW

Spur Suppression: -60dB

Power Supply: 2x1.5V AA battery

Battery Life: less than 10 hours (30mW), less than 15 hours (2mW)
